Butane Gas Regulator with Gauge 21MM - Clip on Calor 30mbar

Designed for straightforward, controlled gas use, the Butane Gas Regulator with Gauge from Calor is a clip-on regulator for butane cylinders, complete with a safety pressure gauge for clear pressure monitoring. It clips onto a butane gas tank with a 21mm clip-on valve; simply attach it to the cylinder and turn the switch when you’re ready to use your appliance.

Suitable for a range of compatible equipment, it can be used with gas cookers, BBQs and patio heaters. The hose nozzle is sized to suit a standard 8mm gas hose, while the unit requires a minimum of 150mm diameter space on the bottle for fitting. Conforming to EN16129, it’s specified for use across a working temperature range of -20°C to 50°C.

Key features

• Clip-on regulator with safety pressure gauge
• Fits butane cylinders with a 21mm clip-on valve
• 8mm hose nozzle for connection to a standard 8mm gas hose
• Requires a minimum 150mm diameter space on the bottle
• Conforms to EN16129

Specifications

• Outlet pressure: 28–30mBar
• Capacity: 1.5KG/h
• Inlet pressure: 0.3–7.5 Bar
• Working temperature: -20°C to 50°C
• Inlet connection: G53
• Outlet connection: H50
• Product code: SFZZNCGRC1030G
• Product weight: 0.345kg

Rackhams Reference : D5PJG2G1WB
