Chain Block and Push Trolley Combination 0.5T 3M (Beam Girder Tackle Manual)

Designed for practical lifting tasks, this Chain Block and Push Trolley Combination provides an all-in-one solution for positioning and raising loads along a steel beam. With a safe working load of 0.5 ton (500KGS) and a 3 metre lift, it offers a straightforward manual set-up for workshops and industrial environments where an adjustable lifting point is required.

The push trolley attaches to steel beams and is recommended for beam sizes from 68MM to 126MM, allowing the lifting point to be positioned as needed. The chain block is manufactured with a chain guide to support smooth chain operation, while steel construction is intended to make it easier to use and transport. For added security in use, the safety hooks are drop forged and heat treated.

Key features

• Safe working load: 0.5 ton (500KGS)
• Lift height: 3 metre
• Recommended beam size: 68MM–126MM
• Chain guide for smooth chain operation
• Drop forged, heat treated safety hooks
• Supplied with a test certificate (sent via email)

Sizing

• Hand chain EWL: 2.9M
• Load chain diameter: 5MM
• Trolley: 195MM x 215MM
• Overall height: 290MM
