Ecohome Insulation Timber Frame Multifoil Insulation Kit

From Ecohome Insulation, the Timber Frame Multifoil Insulation Kit is a complete system for insulating timber frame walls. Designed for 89mm studs or deeper, it combines YBS SuperQuilt for the internal wall with YBS BreatherFoil FR for the external side, offering a practical solution where a range of U values is required for Building Control.

Within the system, SuperQuilt provides thermal performance and can act as a vapour control layer when fully taped and sealed, while BreatherFoil FR adds insulation and also functions as a breathable external membrane. Depending on the timber frame construction, different U values can be achieved. For lower U values such as 0.18, the source recommends installing two layers of SuperQuilt internally with one layer of BreatherFoil FR externally.

Key features

• Designed for timber frame walls with 89mm studs or deeper
• Combines YBS SuperQuilt internally with YBS BreatherFoil FR externally
• YBS SuperQuilt provides thermal performance
• Acts as a vapour control layer when fully taped and sealed
• YBS BreatherFoil FR provides additional insulation
• Also acts as a breathable external membrane

Sizing

• 33m² kit
• YBS SuperQuilt: 3 rolls, 1.2m x 10m, covering 36m²
• YBS BreatherFoil FR: 1 roll, 1.35m x 25m
• Thermaseal Foil Joining Tape: 75mm x 50m

What's included

• 3 rolls of YBS SuperQuilt
• 1 roll of YBS BreatherFoil FR
• Thermaseal Foil Joining Tape

Please note

A heavy duty staple gun and 5,000 staples are included with 66m² kits or larger.

Rackhams Reference : QRNICLX84G
