ENER-J 12V 10A SMPS 120W DC Metal Power Supply for LEDs

Built for stable indoor power delivery, the Ener-J 12V 10A SMPS 120W DC metal power supply is a constant voltage single output unit suited to LED and security applications. Its metal housing and fan-free construction keep the design straightforward, while free air convection provides cooling during operation.

This power supply accepts an input voltage of 100-240V AC with 50/60Hz input frequency, and delivers a 12V DC output. Output current is rated at 0-8A with a 10A peak, while output power is 0-100W with a 120W peak. A +V ADJ variable resistor is included for adjustment, and the unit is rated IP20 for indoor, non-waterproof use.

Key features

• Constant voltage single output
• 12V DC output voltage
• 0-8A output current with 10A peak
• 0-100W output power with 120W peak
• Metal housing
• Silver finish
• IP20 rated for indoor, non-waterproof use
• +V ADJ variable resistor

Specifications

• Input voltage: 100-240V AC (264V AC peak)
• Input frequency: 50/60Hz
• Output voltage: 12V DC
• Output current: 0-8A (10A peak)
• Output power: 0-100W (120W peak)
• Output frequency: 65k Hz
• Working environment: -20~+60 Celsius, 20%~90% RH
• Cooling method: Free air convection
• Fan: No

Rackhams Reference : AAZJ1P7AWH
