Monster Racking Combi Spray Drying Rack Trolley x 4 & 3 Connectors

Built for paint shops and workshop drying areas, this Monster Racking bundle combines 4 spray drying rack trolleys with 3 2-way connectors for a flexible multi-rack setup. The system offers over 100 different orientation and 33 different width combinations, allowing the racks to be used individually, linked together for greater capacity, or arranged in a more compact configuration.

Each trolley has 15 drying layers with 55cm bars and an 85mm gap between bars to keep items separated during drying. The blue powder-coated steel construction provides a robust frame, while removable plastic sleeves on each drying bar make cleaning easier. Four 360 degree castor wheels on each trolley allow smooth repositioning around the workspace.

Key features

• 4 spray drying rack trolleys and 3 2-way connectors
• 15 drying layers per rack
• 25kg weight capacity per layer
• Total weight capacity: 375kg
• Blue powder-coated steel construction
• Over 100 different orientation and 33 different width combinations
• 4 heavy-duty 360 degree castor wheels on each trolley

Specifications

• Bar length: 55cm / 0.55m / 21.7”
• Gap between bars: 85mm / 8.5cm / 3.3”
• Number of layers: 15
• Weight: 26.05kg
• 2-way separator weight: 3.5kg
• Hand bolt length: 115mm / 11.5cm / 4.5”

Sizing

• Height: 181.5cm / 1.8m / 71.5”
• Minimum rack width: 35cm / 0.35m / 13.8”
• Maximum rack width: 65cm / 0.65m / 25.6”
• Depth: 59.3cm / 0.59m / 23.2”
• 2-way separator height: 300mm / 30cm / 11.8”
• 2-way separator width: 597mm / 59.7cm / 23.5”
• 2-way separator depth: 38mm / 3.8cm / 1.5”

What's included

• 4 x spray drying rack trolleys
• 3 x 2 way connector
• 12 x hand bolts

Care and maintenance

Removable plastic sleeves on each drying bar allow easier cleaning and maintenance.

Rackhams Reference : 5RD1W1PXKS
