Snatch Block with Shackle 2T 3" (Swivel Heavy Duty Lifting 2 Ton 3 Inch)

Designed for towing, pulling and overhead lifting, these heavy duty Snatch Blocks are suited to demanding tasks such as off-road winching and recovery. Each block is intended for use with wire rope and features a gate that allows the rope to be placed onto the sheave without threading it through the block, helping to speed up set-up when conditions are tight.

Fitted with a bush sheave, these pulley blocks are not suitable for high-speed applications. They conform to BS EN 13157: 2004 + A1: 2009 and have a factor of safety of 4:1.

Key features

• Suitable for towing, pulling and overhead lifting
• Ideal for off-road winching and recovery applications
• Designed for use with wire rope
• Gate design allows rope placement onto the sheave without threading
• Bush sheave fitted; not suitable for high-speed applications
• Conforms to BS EN 13157: 2004 + A1: 2009
• Factor of safety: 4:1
• Available with safety hook or safety shackle

Sizing

• 3 inch (75mm): SWL 2 ton; front width 82mm; side width 77.6mm; overall height 290mm; suits wire diameter 7-9mm (safety shackle)
• 4.5 inch (114mm): SWL 4 ton; front width 120mm; side width 70mm; overall height 365mm; suits wire diameter 10-12mm (safety shackle)
• 6 inch (150mm): SWL 8 ton; front width 150mm; side width 160mm; overall height 492mm; suits wire diameter 20-22mm (safety shackle)
• 6 inch (150mm): SWL 8 ton; front width 160mm; side width 93mm; overall height 480mm; suits wire diameter 16mm (safety shackle)
• 8 inch (203mm): SWL 8 ton; front width 210mm; side width 93mm; overall height 530mm; suits wire diameter 20-22mm (safety shackle)
• 8 inch (203mm): SWL 15 ton; front width 210mm; side width 100mm; overall height 665mm; suits wire diameter 22-24mm (safety shackle)
• 10 inch (250mm): SWL 12 ton; front width 262mm; side width 180mm; overall height 700mm; suits wire diameter 24-26mm (safety shackle)
• 12 inch (300mm): SWL 15 ton; front width 305mm; side width 195mm; overall height 775mm; suits wire diameter 24-26mm (safety shackle)
• 14 inch (357mm): SWL 22 ton; front width 355mm; side width 170mm; overall height 952mm; suits wire diameter 28-32mm (safety shackle)
• 16 inch (406mm): SWL 30 ton; front width 415mm; side width 140mm; overall height 1019mm; suits wire diameter 32-35mm (safety shackle)
• 3 inch (75mm): SWL 2 ton; front width 80mm; side width 80mm; overall height 295mm; suits wire diameter 7-9mm (hook)
• 4.5 inch (114mm): SWL 4 ton; front width 120mm; side width 75mm; overall height 360mm; suits wire diameter 10-12mm (hook)
• 6 inch (150mm): SWL 8 ton; front width 160mm; side width 110mm; overall height 510mm; suits wire diameter 20-22mm (hook)
• 6 inch (150mm): SWL 8 ton; front width 160mm; side width 110mm; overall height 409mm; suits wire diameter 16-18mm (hook)
• 8 inch (203mm): SWL 8 ton; front width 210mm; side width 100mm; overall height 555mm; suits wire diameter 20-22mm (hook)
• 8 inch (203mm): SWL 15 ton; front width 210mm; side width 110mm; overall height 667mm; suits wire diameter 22-24mm (hook)
• 10 inch (250mm): SWL 12 ton; front width 260mm; side width 130mm; overall height 700mm; suits wire diameter 24-26mm (hook)
• 12 inch (305mm): SWL 15 ton; front width 310mm; side width 133mm; overall height 797mm; suits wire diameter 26-28mm (hook)
• 14 inch (357mm): SWL 22 ton; front width 365mm; side width 140mm; overall height 960mm; suits wire diameter 28-32mm (hook)
• 16 inch (406mm): SWL 30 ton; front width 415mm; side width 140mm; overall height 1027mm; suits wire diameter 32-35mm (hook)

Rackhams Reference : 31HF5JUVWI
