Traditional 3 Column Radiator - 1500 x 200mm - Raw Metal

Designed to bring an industrial edge to classic heating, this traditional 3 column vertical Radiator in raw metal makes a striking feature on the wall while delivering dependable warmth. Crafted from premium 1.5mm carbon steel and finished with a lacquer coating, it’s made for everyday living, with a durable surface that helps it keep its character over time.

With a 1500 x 200mm profile, it suits a range of spaces and layouts, while standard 0.5" BSP inlets/outlets give you the freedom to choose valves to match your scheme. Tested to BS EN 442 and ISO9001:2015 standards and supplied with fixtures and fittings for installation, it’s a considered choice for UK and EU heating systems, backed by a 15-year guarantee.

Key features

• Raw metal colour with lacquer coating finish
• Premium 1.5mm carbon steel construction
• BTU rating @ 60: 3047
• Watt rating @ 60: 893
• Standard 0.5" BSP bore inlets/outlets
• Max working temperature: 95°C
• Max working pressure: 10 Bar (test pressure: 13 Bar)
• 15-year guarantee

Sizing

• Height: 1500mm / 150cm / 59.1”
• Width: 200mm / 20cm / 7.9”
• Radiator depth: 100mm / 10cm / 3.9”
• Depth with bracket: 110mm / 11cm / 4.3”
• Valve-to-valve height: 1424mm / 142.4cm / 56.1”
• Distance from wall to centre of inlet: 60mm / 6cm / 2.4”
• Gap between tubes: 45mm / 4.5cm / 1.8”
• Individual tube size: 25mm / 2.5cm / 1”

What's included

• 1 x Traditional 3 Column Radiator
• 4 x Secure brackets
• 1 x Practical fixing kit
• 1 x Flexible cleaning brush

Please note: Colours shown are as accurate as possible, though may vary slightly depending on your screen settings.
