20MM Wire Rope Grips x10 - DIN741 Galvanised Cable Clamp

Designed for secure wire rope terminations, these 20mm galvanised commercial Wire Rope Grips from DIN741 are a practical choice for forming loops in wire rope. Supplied in a quantity of 10, they suit 20mm wire rope and are commonly used where wire rope is fitted aboard boats, in public areas and for yacht rigging. A galvanised finish provides corrosion resistance for demanding environments.

Key features

• Suits 20mm wire rope
• DIN741 commercial wire rope grip
• Galvanised finish for corrosion resistance
• Quantity: 10
• Product code: SFCOMG20
• Product weight: 2.15kg

Sizing

• A: 41mm
• B: 20mm
• C: 27mm
• D: 12mm
• E: 75mm
• F: 26.5mm
• G: 54mm

Care

Prior to fitting, grease the threads on the nuts and bolts well.

Safety information

• Space grips at least 6 times the diameter of the rope
• Orientate the grip correctly: place the U-bolt on the unloaded end of the rope
• Tighten each nut evenly and in turn to achieve the recommended torque settings
• Leave unused for 24 hours, then re-check torque settings and re-tighten if necessary
• After first application of the load, re-check torque settings and re-tighten if necessary
• During service, periodically check torque settings
