Equip2clean Gorilla Power GPWP3D 3" Dirty / Clean Trash Water Pump

Gorilla Power GPWP3D — 3" Dirty/Clean TRASH Water Pump (Petrol, 208cc)

Built for flood water, pits, trenches and irrigation, the GPWP3D moves serious water fast — and doesn’t flinch at debris. It handles solids up to 28 mm, reaches a max head of 25 m, and delivers up to 45 m³/hr (≈ 750 L/min) with a reliable 208 cc 4-stroke engine.

Where This Model Sits in the Gorilla Power Pump Range

From compact clean-water transfer to high-throughput trash pumps — this 3″ GPWP3D is the heavy mover in the line-up.

• GPWP2 — 2″ Clean-Water
• GPWP3D — 3″ Dirty/Clean (Trash)

Performance at a Glance

• Flow: 45 m³/hr (≈ 750 L/min)
• Max Head: 25 m
• Suction Height (max): 7 m
• Solids Handling: Ø 28 mm

Tip: Actual flow reduces as delivery height (head) increases and with hose friction. Keep suction runs short, airtight, and with a straight path.

Key Features

• Dirty & clean water compatible — handles solids up to 28 mm.
• 208 cc 4-stroke petrol — dependable cold starts & strong torque.
• High throughput — up to 45 m³/hr for rapid dewatering.
• Rugged frame — built to shrug off site knocks and transport.
• Quick to deploy — priming port and included strainer & hose fittings.
• Fuel shut-off — safer transit and maintenance.

Ports, Fittings & Controls

• 3″ Suction (with strainer): Use reinforced suction hose + clamps. Keep runs short & airtight
• 3″ Discharge: Pairs well with 3″ lay-flat hose for rapid outflow
• Fuel valve / Choke / Recoil: Simple controls; close the fuel valve for transport

Application Guide

• Pool / clean tank water: None — Easy
• Flood water (mud/leaves): ≤ 20 mm — Yes
• Pond / irrigation channels: ≤ 25 mm — Yes
• Trenches / foundations: ≤ 28 mm — Yes (trash-capable)
• Sand-laden water: Fine–coarse — OK (abrasion aware)

Not for thick slurries, oils, or chemicals. Always check compatibility and solids size before use.

Setup & Use Tips

• Prime before starting — fill pump housing with clean water to protect seals.
• Suction best-practice — keep suction hose short, straight and airtight with a foot valve/strainer.
• Head vs flow — higher discharge height = lower flow; use the largest practical hose.
• Maintenance — rinse after dirty jobs; inspect strainer and replace worn seals promptly.
• Fuel & storage — close fuel valve; store dry and frost-free.

Technical Specifications

• Model: GPWP3D
• Inlet / Outlet: 3″ (80 mm)
• Engine: 4-stroke petrol, 208 cc
• Suction Height (max): 7 m
• Total Head (max): 25 m
• Flow (max): 45 m³/hr (≈ 750 L/min)
• Solids Handling: Up to Ø 28 mm
• Dimensions (L×W×H): 605 × 455 × 450 mm
• Net Weight: 38.5 kg

Instruction Manual (PDF)
