Fixaball M20 Through Bolts Heavy Duty Masonry Anchor BZP ETA Approved

For heavy-duty anchoring in non-cracked concrete, masonry and non-porous stone, the Fixaball M20 through bolt is supplied in zinc and ETA approved. This expansion anchor suits installations where the fixing is passed through the fixture after positioning, with the hole matching the fixing diameter.

The cold formed body supports consistent dimensional accuracy and material stability. Reduced embedment is suitable where contact with rebars or reinforcement cages needs to be avoided. Available in multiple lengths, this anchor is intended for use in compact concrete with insignificant porosity.

Key features

• M20 through bolt expansion anchor
• Zinc finish
• ETA approved
• Suitable for non-cracked concrete, masonry, brick, blocks and non-porous stone
• Reduced embedment option to help avoid contact with rebars or reinforcement cages
• Cold formed body for consistent dimensional accuracy and material stability

Specifications

• Installation temperature range for base material: -5 / + 40 ºC
• 80 ºC for a short period of time
• Drilling must respect the specified minimum depth and diameter
• Specified torque must be applied with a torque wrench

Available options

• 130mm length
• 170mm length
• 215mm length

Sizing

• Anchor hole size: 20mm
• Anchor length: 130mm
• Anchor length: 170mm
• Anchor length: 215mm
• M20
• 20
• 125
• 5
• 20/ 22
• 160
• 40
• 20
• 200
• 80
• 60
• 300
• 180
• 160

Safety information

• Check the concrete strength before installation to ensure the class or standard is suitable.
• The concrete base must be compact with insignificant porosity.
• Minimum installation depth values must always be respected for anchor depth, anchor-to-anchor distances and anchor-to-edge distances.
• Drill perpendicular to the base material surface and maintain the specified minimum depth and diameter.
• Take special care when drilling near reinforcement areas to avoid damage.
• If drilling is aborted after encountering reinforcement, drill a new hole at a minimum distance of at least twice the aborted drill hole diameter, unless the aborted hole has been filled with high-resistant mortar.
• Clean holes thoroughly to remove dust and debris using a suitably sized brush.
• When temperature is below 0ºC, ensure water does not seep into the hole.
• Do not apply any intermediate layer between the material being fixed and the washer, including sealing products.
• If the holes in the material being fixed are larger than required, a thicker washer of bigger diameter is necessary.
