GearHooks 4 Bike Wall Rack Hanging Garage Storage - Space Saving Wall Rack for any 4 Bikes

The best UK designed and manufactured wall mounted bike rack you can buy

What is a wall mounted bike rack?

A wall mounted bike rack will free up space in your garage or shed by getting your bikes off the floor (where they take up space and could get damaged) and mounts them on the wall.

If you want to get 4 bikes mounted on the wall quickly and easily, this is the answer.

Unlike individual bike hooks that each mount with 3 or 4 fiddly little screws, this wall mounted bike rack fits with just 3 holes. You can add or move the hooks with just an Allen key (which we provide).

It's ideal for 4 road bikes or a mix of road and mountain bikes. You don't even have to lift heavy bikes. Just roll them up on their back wheel and hook the front wheel.

It’s super-strong and tough enough for a garage or shed and will also look fantastic in your home or office.

You can even lock the bike to the rail using a cable lock and the loop on top of the bike hook.

Best of all, it's designed and made in the UK and is so well engineered that we offer a Lifetime Warranty.

You don’t even have to lift heavy bikes.

Simply pull on the back brake, take a couple of steps backwards (the bike will rise onto its back wheel) and roll it forwards until you can hook the front wheel. If you are able to lift the bikes, you can mount the rail higher on the wall to keep the floor clear for easy cleaning.

Main Features

• Wall mounted bike rack for 4 bikes
• 1 metre long rail + 4 bike hooks
• Any bike type - road, MTB, BMX, Downhill, electric (even tandems and recumbents) or a mix of bike types (see capacity note below)
• Any frame size - Child or adult bike. Any mix of frame sizes
• Any wheel size - 20" - 29"
• Any tyre size -  up to 3”
• Heavy duty steel rail and hooks.
• Bike hooks mount anywhere on the rail and can be added, moved or adjusted easily with just an Allen key
• No need to lift heavy bikes. Just roll them up on the back wheel
• Lighter bikes can be mounted high on the wall to keep the floor clear
• Up to 200kg max weight for NoLift or 75 kg max for ClearFloor
• Designed and manufactured in the UK.
• Lifetime warranty

To help you choose the right capacity bike rack:

This wall mounted bike rack is designed for 4 road bikes or a mixture of road and mountain bikes.

It includes a 1 metre long rail and 4 bike hooks plus all the fittings you need for most wall types.

The number of bikes that can easily be stored on a 1M long rail depends on the types of bikes and handlebar width. 4 road bikes are easier to store than 4 mountain bikes.

To make the bikes easy to get out and put away, we would recommend a maximum of 3+1 or 2+2 mountain/downhill bikes + road bikes per rail.

We also manufacture wall mounting bike racks for 3 mountain or road bikes (BR3) or a mixture or 3+2 bikes (BR5) in this range. They all have a 1M long rail with 3, 4 or 5 bike hooks.

If you have a lot of bikes, two or more wall mounted bike racks can be mounted side by side or offset, one above the other.

There's also space for all your other biking gear like helmets, bags, track pumps, work stands, spare parts and tools in between the bikes to really maximise the use of wall space. Extra GearHooks® are available for this.

In-built Security as standard

If you want to be able to secure your bikes on the rack you can use the loop on the top of the bike hooks. Just feed a cable lock (not supplied) through the loop and the front wheel. For added security use a longer cable and feed it through the frame. For even more security you can drill out the hex head on the fixing screw to make it almost impossible to remove the hook. If the hooks are fitted over the rail fixings, a thief can’t even unscrew the rail. All of this will prevent opportunist theft and is a huge deterrent to even the most determined thief.

Specification

The GearHooks® BR4 wall mounted bike rack includes;

• 1 x 1 metre long cold rolled steel rail galvanised and powder coated
• Your choice of 8 different colours
• 2 x black plastic end caps
• 3 x hex head wall bolts (Allen Key) for wood or plasterboard battens
• 3 x expanding nylon fixings for brick, block, stone or concrete
• plus
• 4 x cold formed steel hooks with bright zinc plating to prevent corrosion
• 4 x soft rubber sleeves to hold and protect your bike wheels
• 4 x CNC machined clamps in black engineering polymer that is stronger than aluminium
• 4 x M8 sliding nuts to position and adjust the hooks anywhere on the rail
• 4 M8 hex head bolts (Allen Key)
• Full fitting and use instructions
• No quibble Lifetime guarantee

Fitting Advice/Documentation/Fitting Instructions

Once you have fixed the GearRail™ to the wall, with just 3 heavy duty fixings, you’ll never need to drill another hole. You can fit, move and adjust the bike hooks and accessory hooks with just an Allen key.

Once they are locked in place the hooks cannot drop off or move about so it’s just like a fully welded rack.
