Living and Home Ventilation Wall-Mounted Exhaust Axial Fan 14 to 24 inch

Built for practical ventilation in busy spaces, the Living and Home wall-mounted exhaust axial fan supports air circulation while helping to remove stale air, odours and excess moisture. With a copper motor and a 5-blade design, it suits a range of settings including bathrooms, kitchens and workshops. A double-side metal wire shell adds a robust, safety-focused finish, while the wall-mounted format keeps installation neat and space-conscious.

Available in sizes from 14 inch to 24 inch, each option is specified with its own dimensions, electrical ratings and airflow performance. The fan runs on a single-phase 220-240V, 50HZ supply and comes in a black iron construction.

Key features

• Wall-mounted exhaust axial fan
• Copper motor
• Double-side metal wire shell
• 5-blade design
• Single-phase operation
• Black finish
• Iron construction

Specifications

Sizes & dimensions

• 41.5cm Dia x 17.5cm H (14 inch)
• 46.6cm Dia x 17.5cm H (16 inch)
• 56.5cm Dia x 21.5cm H (20 inch)
• 62cm Dia x 23cm H (22 inch)
• 66.8cm Dia x 27.3cm H (24 inch)

Electrical

• Voltage: 220-240V, 50HZ
• Phase: 1
• Input current: 0.73A (14 inch); 0.8A (16 inch); 1.6A (20 inch); 2.4A (22 inch); 3.3A (24 inch)
• Capacitance: 4uF (14 inch); 6uF (16 inch); 10uF (20 inch); 12uF (22 inch); 16uF (24 inch)
• Power consumption: 145W (14 inch); 180W (16 inch); 350W (20 inch); 500W (22 inch); 710W (24 inch)

Performance

• Speed: 1380 (r/min)
• Air volume: 2500M3/H (14 inch); 3500M3/H (16 inch); 6570M3/H (20 icnh); 8700M3/H (22 inch); 10850M3/H (24 inch)
• Total pressure: 140Pa (14 inch); 150Pa (16 inch); 165Pa (20 inch); 240Pa (22 inch); 300Pa (24 inch)
• Noise: 65db (A) (14 inch); 75db (A) (16 inch); 68db (A) (20 inch); 74db (A) (22 inch); 76db (A) (24 inch)

In the box

• 1 x Exhaust fan

Please note: Colours may appear slightly different in person than on your screen.
