Snatch Block Swivel Hook 4T 4.5" (Lifting Pulley 4 Ton 4.5 Inch Lightweight)

Designed for towing, pulling and overhead lifting, these snatch blocks offer a practical solution for off-road winching and recovery work. Each heavy duty pulley block is intended for use with wire rope and features a gate that allows the rope to be placed onto the sheave without threading it through the block, helping to speed up set-up when conditions demand it.

Fitted with a bush sheave, these snatch blocks are not suitable for high-speed applications. They conform to BS EN 13157: 2004 + A1: 2009 and have a factor of safety of 4:1. Options are available with a safety hook or a safety shackle, with a range of sizes and safe working loads to suit different wire diameters.

Key features

• Suitable for towing, pulling and overhead lifting
• Ideal for off-road winching and recovery applications
• Designed for use with wire rope
• Gate design allows rope placement onto the sheave without threading
• Bush sheave fitted; not suitable for high-speed applications
• Conforms to BS EN 13157: 2004 + A1: 2009
• Factor of safety: 4:1
• Available with safety hook or safety shackle

Sizing

• 3 inch (75MM): SWL 2 Ton; front width 82MM (shackle) / 80MM (hook); side width 77.6MM (shackle) / 80MM (hook); overall height 290MM (shackle) / 295MM (hook); suits wire diameter 7-9MM
• 4.5 inch (114MM): SWL 4 Ton; front width 120MM; side width 70MM (shackle) / 75MM (hook); overall height 365MM (shackle) / 360MM (hook); suits wire diameter 10-12MM
• 6 inch (150MM): SWL 8 Ton; front width 150MM (shackle) / 160MM (shackle/hook); side width 160MM or 93MM (shackle) / 110MM (hook); overall height 492MM or 480MM (shackle) / 510MM or 409MM (hook); suits wire diameter 20-22MM, 16MM, or 16MM-18MM
• 8 inch (203MM): SWL 8 Ton or 15 Ton; front width 210MM; side width 93MM or 100MM (shackle) / 100MM or 110MM (hook); overall height 530MM or 665MM (shackle) / 555MM or 667MM (hook); suits wire diameter 20-22MM or 22-24MM
• 10 inch (250MM): SWL 12 Ton; front width 262MM (shackle) / 260MM (hook); side width 180MM (shackle) / 130MM (hook); overall height 700MM; suits wire diameter 24-26MM
• 12 inch (300MM or 305MM): SWL 15 Ton; front width 305MM (shackle) / 310MM (hook); side width 195MM (shackle) / 133MM (hook); overall height 775MM (shackle) / 797MM (hook); suits wire diameter 24-26MM or 26-28MM
• 14 inch (357MM): SWL 22 Ton; front width 355MM (shackle) / 365MM (hook); side width 170MM (shackle) / 140MM (hook); overall height 952MM (shackle) / 960MM (hook); suits wire diameter 28-32MM
• 16 inch (406MM or 406mm): SWL 30 Ton; front width 415MM; side width 140MM; overall height 1019MM (shackle) / 1027MM (hook); suits wire diameter 32-35MM
