Snatch Block Swivel Hook 8T 8" (Lifting Pulley 8 Ton 8 Inch Lightweight)

Designed for towing, pulling and overhead lifting, these heavy duty Snatch Blocks are built for demanding recovery and winching set-ups, including off-road use. Each block is intended for use with wire rope and features a gate that lets you place the rope onto the sheave without threading it through the block, helping to speed up rigging when time matters.

Fitted with a bush sheave, these pulley blocks are not suitable for high-speed applications. They conform to BS EN 13157: 2004 + A1: 2009 and are made to a 4:1 factor of safety. Used correctly, they can help lessen the load on the winch during recoveries and off-road winching.

Key features

• Suitable for towing, pulling and overhead lifting
• Designed for use with wire rope
• Gate design allows rope placement onto the sheave without threading
• Bush sheave fitted; not suitable for high-speed applications
• Conforms to BS EN 13157: 2004 + A1: 2009
• Factor of safety: 4:1
• Available with safety hook or safety shackle

Sizing

• 3 inch (75MM): SWL 2 Ton; front width 82MM (shackle) / 80MM (hook); side width 77.6MM (shackle) / 80MM (hook); overall height 290MM (shackle) / 295MM (hook); suits wire diameter 7-9MM
• 4.5 inch (114MM): SWL 4 Ton; front width 120MM; side width 70MM (shackle) / 75MM (hook); overall height 365MM (shackle) / 360MM (hook); suits wire diameter 10-12MM
• 6 inch (150MM): SWL 8 Ton; front width 150MM (shackle) / 160MM (shackle & hook); side width 160MM (shackle) / 93MM (shackle) / 110MM (hook); overall height 492MM (shackle) / 480MM (shackle) / 510MM (hook) / 409MM (hook); suits wire diameter 20-22MM (shackle & hook) or 16MM (shackle) or 16MM-18MM (hook)
• 8 inch (203MM): SWL 8 Ton; front width 210MM; side width 93MM (shackle) / 100MM (hook); overall height 530MM (shackle) / 555MM (hook); suits wire diameter 20-22MM
• 8 inch (203MM): SWL 15 Ton; front width 210MM; side width 100MM (shackle) / 110MM (hook); overall height 665MM (shackle) / 667MM (hook); suits wire diameter 22-24MM
• 10 inch (250MM): SWL 12 Ton; front width 262MM (shackle) / 260MM (hook); side width 180MM (shackle) / 130MM (hook); overall height 700MM; suits wire diameter 24-26MM
• 12 inch (300MM) shackle: SWL 15 Ton; front width 305MM; side width 195MM; overall height 775MM; suits wire diameter 24-26MM
• 12 inch (305MM) hook: SWL 15 Ton; front width 310MM; side width 133MM; overall height 797MM; suits wire diameter 26-28MM
• 14 inch (357MM): SWL 22 Ton; front width 355MM (shackle) / 365MM (hook); side width 170MM (shackle) / 140MM (hook); overall height 952MM (shackle) / 960MM (hook); suits wire diameter 28-32MM
• 16 inch (406MM/406mm): SWL 30 Ton; front width 415MM; side width 140MM; overall height 1019MM (shackle) / 1027MM (hook); suits wire diameter 32-35MM
