Wire Rope Pulling Hoist Winch 800KG (ACE 0.8T Lifting 1.25T Puller with 20M Rope)

Designed for demanding lifting and pulling tasks, the ACE Wire Rope Pulling Hoist Winch is a portable Wire Rope Hoist supplied with 20 metres of steel wire rope and a detachable, extendable aluminium handle. Built with an aluminium body housing steel mechanisms, it’s suited to a wide range of applications including construction, oil and chemical companies, mines, quarries, agricultural and forestry work.

Engineered for controlled handling of loads, this hoist supports pulling, lifting, lowering and securing. A hook with a safety catch helps prevent loads from slipping during lifting or pulling, while overload protection is included to support safe operation. For added reassurance, the hoist conforms with BS EN 13157: 2004 + A1: 2009 and is supplied with a test certificate via email. Spare shear pins can be included if required; these act as a safety mechanism to help prevent exceeding the safe working load.

Key features

• Aluminium body with steel mechanisms
• Includes 20 metres of steel wire rope
• Detachable, extendable aluminium handle
• Hook with safety catch
• Overload protection
• Conforms with BS EN 13157: 2004 + A1: 2009
• Test certificate supplied via email
• Optional spare shear pins (brass)

Sizing

• 800kg: 0.8T lifting capacity; 1.25T pulling capacity; 8.3mm wire rope diameter; 426mm overall length; 238mm overall height; 64mm overall width
• 1600kg: 1.6T lifting capacity; 2.5T pulling capacity; 11mm wire rope diameter; 545mm overall length; 284mm overall height; 97mm overall width
• 3200kg: 3.2T lifting capacity; 5.6T pulling capacity; 16mm wire rope diameter; 660mm overall length; 325mm overall height; 116mm overall width
• 5400kg: 5.4T lifting capacity; 8T pulling capacity; 20mm wire rope diameter; 930mm overall length; 385mm overall height; 150mm overall width
