T-mech Drywall & Plasterboard Lifter Hoist 16ft

From T-Mech, this 16ft Drywall & Plasterboard Lifter Hoist is designed to help position panels for wall and ceiling work with less manual handling. The heavy-duty steel frame and tilting action make it suitable for level, sloped and vaulted surfaces, supporting a wide range of working angles.

Built to take on larger boards, it accommodates panels from 4ft to 16ft with a maximum load capacity of 68kg (150lb). For smoother manoeuvring around the job, the hoist runs on 10cm swivelling caster wheels, with brakes to help keep it securely in place while lifting. When the work is done, the foldable frame makes it easier to transport and store, and it can be assembled and disassembled without tools.

Key features

• Heavy-duty drywall lifter hoist with tilting action for varied angles of work
• Suitable for panels between 4ft and 16ft
• Maximum weight capacity of 68kg (150lb)
• 10cm swivelling caster wheels with brakes
• Foldable frame for easier transport and storage
• No tools required for assembly and disassembly
• CE certified

Specifications

• Material: Steel
• Colour: Orange
• Finish: Powder coated
• Product weight: 38.72kg
• Weight capacity: 68kg / 150lb
• Wheel size: 10cm / 100mm / 3.9”

Sizing

• Min board size: 4ft / 1.2m / 48”
• Max board size: 16ft / 4.9m / 192”
• Min height: 4.8ft / 1.46m / 57.5”
• Max height: 16ft / 4.9m / 192”
• Width: 142cm / 1.4m / 56”
• Depth: 122cm / 1.2m / 48”
