Trailer Jockey Wheel Ribbed 48MM with Clamp (Heavy Duty Solid Rubber Caravan Jockey Guide)

Designed for easier manoeuvring and height adjustment, this 48mm ribbed caravan jockey wheel with clamp is a practical addition to trailer and caravan set-ups. Finished in bright zinc plating to aid rust resistance, it is built for regular transport use where dependable handling matters.

The supplied trailer clamp is intended for holding jockey wheels and prop stands on the side of trailers. Rubber grips on the end of the handle support easier operation, while the clamp opens and closes by screwing clockwise or anti-clockwise. Please note that, due to the zinc plating process, the finish may show blemishes.

Key features

• Maximum load capacity: 400KGS
• Tube diameter: 48MM
• Tyre width x diameter: 56MM x 200MM
• Overall height (min to max): 790MM to 980MM
• Bore length: 60MM
• Bright zinc plated finish to aid rust resistance
• Clamp with rubber handle grips; screw mechanism opens and closes clockwise or anti-clockwise

Sizing

• Clamp overall length x width: 185MM x 63MM
• Distance between centre of holes: 147MM
• Bolt hole diameter: 18MM

Please note

Due to the zinc plating process, the finish may have blemishes.
