1.1 Ton 5" Red Head GMI Double Sheave Block With Swivel Eye Galvanised - 18MM Rope Safety Lifting

Designed for practical lifting and towing tasks, this 3" Double Sheave Pulley Block with Eye is made for use with wire rope and can also be used to re-direct rope where a change of direction is required. Conforming to BS EN 13157:2004+A1:2009, it is supplied with test certification via email for added assurance when specifying equipment for site or workshop use.

With a safe working load (SWL) of 0.4 ton and suitability for 12mm rope diameter, it offers a clear, straightforward option for applications where controlled movement and guidance of rope is needed.

Key features

• Double sheave pulley block with eye
• Suitable for lifting and towing applications
• Can be used to re-direct rope
• Conforms to BS EN 13157:2004+A1:2009
• Test certificate supplied via email
• Safe working load (SWL): 0.4 ton
• Suitable rope diameter: 12mm
• Size: 3"

Sizing

• A: 165mm
• B: 43.5mm
• C: 53.5mm
• D: 12.75mm
• E: 23.75mm
• F: 61mm
• G: 17.5mm
