Fixaball M16 Hex Bolt High Tensile 8.8 BZP DIN 931

For structural fastening where a partially threaded fixing is required, the Fixaball M16 hexagon head bolt is supplied in steel grade 8.8 with a zinc plated finish. This DIN 931 bolt has a part plain shank and is intended for use with a nut and washer.

The range includes multiple M16 lengths, making it suitable where the required shank and thread engagement vary by application. The zinc coating adds moisture resistance to the steel and provides a bright finish for internal use or areas where occasional moisture may be present.

Key features

• M16 metric coarse thread
• Partially threaded with part plain shank
• Steel grade 8.8
• Zinc plated finish
• DIN 931

Specifications

• Thread pitch: 2.0
• Fine thread: 1.5
• Width across flat (s): 23.67 min, 24.00 max
• Spanner size: 24mm
• DIN 931 thread length: 38 for lengths ≥125, 44 for lengths >125≥200, 57 for lengths ≥200
• ISO 4014 thread length: 38 for lengths ≥125, 44 for lengths >125≥200

Available options

• M16 x 45
• M16 x 50
• M16 x 55
• M16 x 60
• M16 x 65
• M16 x 70
• M16 x 75
• M16 x 80
• M16 x 90
• M16 x 100
• M16 x 110
• M16 x 120
• M16 x 130
• M16 x 140
• M16 x 150
• M16 x 160
• M16 x 170
• M16 x 180
• M16 x 190
• M16 x 200
• M16 x 220

Rackhams Reference : 933RF4JX3X
