Fixaball M6 Through Bolts Heavy Duty Masonry Anchor BZP ETA Approved

For concrete, masonry and non-porous stone fixings, the Fixaball M6 through bolt is a zinc-plated heavy duty expansion anchor with ETA approval. It is suited to non-cracked concrete, brick and block, and can be passed through the fixture once the fixing position has been set.

The cold formed body supports consistent dimensional accuracy and material stability. Reduced embedment suitability is stated for applications where contact with rebars or reinforcement cages needs to be avoided.

Key features

• M6 through bolt expansion anchor
• Zinc finish
• ETA Approved
• Suitable for non-cracked concrete, masonry, brick, blocks and non-porous stone
• Cold formed body

Specifications

• Installation temperature range for base material: -5 / + 40 ºC (80 ºC for a short period of time)
• Holes are the same diameter as the fixings
• Specified torque must be applied with a torque wrench

Available options

• 60mm length
• 80mm length

Sizing

• Anchor hole size: 6mm
• Anchor length: 60mm
• Anchor hole size: 6mm
• Anchor length: 80mm
• Diameter: 6
• Length: 50
• Range of joining thickness: 10
• Hole diameter: 7
• Length: 65
• Range of joining thickness: 25
• Hole diameter: 5
• Length: 85
• Range of joining thickness: 45
• Hole diameter: 25
• Length: 100
• Range of joining thickness: 60
• Hole diameter: 40

Safety information

• Check the concrete strength before installation to ensure the class or standard is suitable.
• The concrete base must be compact with insignificant porosity.
• Minimum installation depth values must always be respected for anchor depth, anchor-to-anchor distances and anchor-to-edge distances.
• Drilling must be carried out to the specified minimum depth and diameter, perpendicular to the base material surface.
• Take special care when drilling near reinforcement areas to avoid damage.
• Clean holes thoroughly to remove dust and debris using a suitably sized brush.
• When temperature is below 0ºC, ensure water does not seep into the hole, as this could cause subsequent cracks in the concrete due to ice pressure.
• Do not apply any intermediate layer between the material to be fixed and the washer, including sealing products.
• If holes in the material to be fixed are larger than required, a thicker washer of bigger diameter is necessary.
