Fixaball M8 Socket Cap Allen Screw Bolt A2/304 Stainless Steel

For machine assembly and general fastening, this Fixaball socket cap screw features an M8 metric coarse thread with a 1.25mm pitch. Made from A2 / 304 stainless steel, it has a plain finish and a hexagon socket cap head to suit a 6mm Allen key.

Manufactured to DIN 912 and ISO 4762, it is available in a range of lengths from 10mm to 100mm. Head dimensions are 13.2mm diameter and 8mm height. Stated lengths exclude the head.

Available options

• M8 x 10
• M8 x 12
• M8 x 14
• M8 x 16
• M8 x 18
• M8 x 20
• M8 x 22
• M8 x 25
• M8 x 30
• M8 x 35
• M8 x 40
• M8 x 45
• M8 x 50
• M8 x 55
• M8 x 60
• M8 x 65
• M8 x 70
• M8 x 75
• M8 x 80
• M8 x 85
• M8 x 90
• M8 x 95
• M8 x 100

Key features

• Diameter: M8
• Thread size: M8 x 1.25mm pitch
• Material and finish: A2 / 304 stainless steel, plain finish
• Hexagon socket cap head
• Standards: DIN 912, ISO 4762

Specifications

• Head diameter: 13.2mm
• Head height: 8mm
• Allen key size: 6mm
• Thread type: metric coarse

Sizing

• Available lengths: 10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 22mm, 25mm, 30mm, 35mm, 40mm, 45mm, 50mm, 55mm, 60mm, 65mm, 70mm, 75mm, 80mm, 85mm, 90mm, 95mm, 100mm
• Bolt lengths do not include the head

Rackhams Reference : 85AV1IPJ3H
