x10 M16 Galvanised Forged Straining Screw Eye Eye - Caravan Turnbuckle Open Body

Designed for wire rope applications, these galvanised eye and eye straining screws (turnbuckles) are suited to tightening, tensioning and adjusting where controlled take-up is required. The open-bodied design keeps the thread visible, making it easier to monitor the rate of turning during adjustment. Also used with chain and cable, this style is widely used in the caravanning industry.

Key features

• Galvanised eye and eye straining screw (turnbuckle)
• Open body with visible thread for monitoring the rate of turning
• Suitable for tightening, tensioning and adjusting wire rope applications
• Can also be used with chain and cable
• Popular for caravanning use

Sizing

• 5mm: A 5mm, B 70mm, C 7.5mm, D 117mm, E 164mm (Code: SFFOREE05)
• 6mm: A 6mm, B 109mm, C 9mm, D 165mm, E 249mm (Code: SFFOREE06)
• 8mm: A 8mm, B 111mm, C 9.5mm, D 171mm, E 251mm (Code: SFFOREE08)
• 10mm: A 10mm, B 125mm, C 14mm, D 195mm, E 275mm (Code: SFFOREE10)
• 12mm: A 12mm, B 125mm, C 16mm, D 230mm, E 315mm (Code: SFFOREE12)
• 16mm: A 16mm, B 169mm, C 22mm, D 295mm, E 395mm (Code: SFFOREE16)
• 20mm: A 20mm, B 200mm, C 23.5mm, D 335mm, E 510mm (Code: SFFOREE20)
• 21mm: A 21mm, B 220mm, C 29mm, D 400mm, E 540mm (Code: SFFOREE22)
• 23mm: A 23mm, B 250mm, C 29mm, D 430mm, E 610mm (Code: SFFOREE24)
• 29mm: A 29mm, B 255mm, C 31mm, D 480mm, E 630mm (Code: SFFOREE30)
• 31mm: A 31mm, B 295mm, C 36mm, D 525mm, E 705mm (Code: SFFOREE33)
