x2 34MM DIN1142 Wire Rope Grips Zinc Plated - Cable Clamp Fixing Bulldog Lifting

Designed for rigging and lifting assemblies, these DIN1142 wire rope grips from Rackhams provide a practical way to form secure loops in wire rope or create a temporary join when required. Supplied as a pack of 2, each grip suits 34mm wire rope and features a zinc-plated finish for corrosion resistance, making it suitable for use on board boats as well as for similar applications on land.

For safe, reliable performance, installation should be carried out by a qualified person. Prior to fitting, grease the threads on the nuts and bolts, then tighten each nut evenly in turn to achieve the recommended torque settings. After assembly, leave unused for 24 hours before re-checking torque, and repeat checks after the first application of load and periodically during service. Ensure correct orientation during fitting, with the U-bolt placed on the unloaded end of the rope, and maintain spacing between grips of at least 6 times the diameter of the rope.

Key features

• DIN1142 wire rope grips for lifting assemblies
• Suitable for creating loops or temporary joins in wire rope
• Suits 34mm wire rope
• Zinc-plated finish
• Quantity: 2

Sizing

• A: 63mm
• B: 38.5mm
• C: 45.7mm
• D: 20.9mm
• E: 141mm
• F: 67mm
• G: 106mm

Safety information

• For assemblies designed for lifting purposes, ensure installation is carried out by a qualified person
• Grease the threads on nuts and bolts prior to fitting
• Keep spacing between grips at least 6 times the diameter of the rope
• Fit with the U-bolt on the unloaded end of the rope
• Tighten nuts evenly and in turn to achieve the recommended torque settings
• Leave unused for 24 hours, then re-check torque and re-tighten if required
• After first load application, re-check torque and re-tighten if required
• Periodically check torque settings during service
