Fixaball UNC 1/2" Hex Bolt Set Screws A2 304 Stainless Steel

Available in a range of lengths, these Fixaball UNC 1/2" hexagon bolts and hexagon set screws are made from A2/304 stainless steel with a 13 t.p.i. UNC thread. The selection includes fully threaded set screws and partially threaded hexagon bolts to suit different fastening requirements.

Partially threaded options are intended for use with a nut and washer, while all lengths are measured from the underside of the head to the end of the fastener. A2/304 stainless steel is the regular stainless standard and resists intermittent weathering without corroding or losing its metallic finish.

Available options

• 1/2"-13x1" (FT)
• 1/2"-13x1 1/4" (FT)
• 1/2"-13x1 1/2" (FT)
• 1/2"-13x2" (PT)
• 1/2"-13x2 1/2" (PT)
• 1/2"-13x3" (PT)
• 1/2"-13x3 1/4" (PT)
• 1/2"-13x3 3/4" (PT) request length
• 1/2"-13x4" (PT)
• 1/2"-13x4 1/4" (PT) request length
• 1/2"-13x4 1/2" (PT) request length
• 1/2"-13x5 1/2" (PT) request length
• 1/2"-13x6" (PT)
• 1/2"-13x6 1/2" (PT) request length

Key features

• UNC 1/2" thread
• 13 t.p.i.
• A2/304 stainless steel
• Choice of fully threaded set screws and partially threaded hexagon bolts

Specifications

• DIN 931
• Unified National Coarse (UNC) thread form
• 60 degree flank angle rounded roots and flat crests
• Thread standards agreed upon by standard bodies of Canada, the United Kingdom, and the United States

Sizing

• 1/2"-13x1"
• 1/2"-13x1 1/4"
• 1/2"-13x1 1/2"
• 1/2"-13x2"
• 1/2"-13x2 1/2"
• 1/2"-13x3"
• 1/2"-13x3 1/4"
• 1/2"-13x3 3/4"
• 1/2"-13x4"
• 1/2"-13x4 1/4"
• 1/2"-13x4 1/2"
• 1/2"-13x5 1/2"
• 1/2"-13x6"
• 1/2"-13x6 1/2"
