Monstershop Flat Single Column Radiator & Valves – 1600mm x 420mm – Anthracite Grey

A smart way to update a modern heating setup, the Monstershop Flat Single Column Radiator & Valves combines an anthracite grey radiator with a polished chrome thermostatic valve set. Measuring 1600mm x 420mm, it brings a clean, architectural look to interiors while keeping the profile slim at 46mm deep (73mm with bracket).

Made from 1.5mm carbon steel and finished with triple layered powder coating, it’s built for long-term use and supplied with a flexible cleaning brush to help keep the surface looking its best. Heat output is rated at 2529 BTU @ 50 and 3211 BTU @ 60 (741W @ 50 and 941W @ 60). The angled thermostatic valves use a rotary knob with a 6-28 degrees temperature range, alongside an integrated lock shield valve for water flow regulation.

Key features

• Flat single column radiator with thermostatic valve set
• Size: 1600mm x 420mm
• Colour: anthracite grey
• Heat output: 3211 BTU @ 60
• 6-column design with 60mm x 15mm flat tubes
• Standard 0.5" BSP inlet/outlet size
• CE and UKCA certified; tested to BS EN 442 and ISO9001:2015 standards
• 15-year guarantee (radiator) and 10-year guarantee (valves)

Specifications

Radiator

• Material: 1.5mm carbon steel
• Weight: 16.9kg
• Finish: triple layered powder coating
• Height: 1600mm / 160cm / 63”
• Width: 420mm / 42cm / 16.5”
• Radiator depth: 46mm / 4.6cm / 1.8”
• Depth with bracket: 73mm / 7.3cm / 2.9”
• Gap between tubes: 10mm / 1cm / 0.4”
• Individual flat tube size: 60mm x 15mm
• Number of columns: 6
• BTU rating @ 50: 2529
• BTU rating @ 60: 3211
• Watt rating @ 50: 741
• Watt rating @ 60: 941
• Max working temperature: 95°C
• Max working pressure: 5 Bar
• Test pressure: 6.5 Bar
• Recommended application area: 9m²
• Inlets/outlets size: standard 0.5" BSP bore
• Distance from wall to centre of inlet: 44mm / 4.4cm / 1.7”
• Valve-to-valve height: 1554mm / 155.4cm / 61.2”
• Compatibility: all UK & EU heating systems
• Certifications: CE & UKCA
• Testing: BS EN 442 & ISO9001:2015 standards

Valves

• Material: brass
• Finish: polished chrome
• Weight: 0.9kg
• Style: angled
• Type: thermostatic
• Control style: rotary knob
• Temperature range: 6-28 degrees
• Maximum bar pressure: 12
• Maximum flow temperature: 100 degrees
• Nominal flow rate: 2.8L/m
• Connection: 1/2" x 15mm

In the box

• 1 x Flat Single Column Radiator
• 4 x Secure Brackets
• 1 x Practical Fixing Kit
• 1 x Flexible Cleaning Brush
• 1 x Thermostatic Valve Set

Support & warranty

• Radiator guarantee length: 15 years
• Valve guarantee length: 10 years

Please note: Colours shown are as accurate as possible, though may vary slightly depending on your screen settings.
