0.5 Ton 100MM London Pattern Snatch Block With Safety Hook & Nylon Sheave - 16MM Soft Rope Tested

Designed for lifting and towing applications, this London Pattern Snatch Block with Safety Hook & Nylon Sheave offers a practical way to manage and re-direct rope when setting up a rig. Rated to a safe working load of 0.5 ton and built for use with 16mm soft fibre rope, it’s a considered choice where controlled handling and straightforward rope installation matter.

A side gate allows the rope to be placed directly onto the sheave, avoiding the need to thread the full rope length through the block. This model also includes a built-in becket for added versatility in set-ups. Finished in blue paint, it conforms to BS EN 13157:2004 + A1:2009 and is specified with a 4:1 factor of safety. A test certificate is included and sent via email.

Key features

• Safe working load: 0.5 ton
• Suitable for 16mm soft fibre rope
• London pattern Snatch Block with safety hook
• Nylon sheave
• Side gate for direct rope placement onto the sheave
• Built-in becket
• Blue painted finish
• Conforms to BS EN 13157:2004 + A1:2009

Sizing

• A: 340mm
• B: 20mm
• C: 100mm
• D: 59mm
• E: 20mm
• F: 108mm
