1 Ton 100MM Double Sheave Snatch Block With Swivel Hook Blue Painted - 10MM Wire Rope Safety Lifting

Designed for controlled lifting, towing and rope re-directing, this double sheave Snatch Block from Rackhams’ lifting range features a swivel hook for flexible positioning in use. The side gate allows 10mm wire rope to be placed directly onto the sheave, avoiding the need to thread the full rope length through the block.

Finished in blue paint and built with a becket, it is specified with a 1 ton safe working load and a 4:1 factor of safety. This model conforms to BS EN 13157: 2004 + A1: 2009, and a test certificate is included and sent via email.

Key features

• Double sheave Snatch Block with swivel hook
• Side gate for direct rope loading onto the sheave
• Suitable for use with 10mm wire rope
• Built-in becket
• Safe working load: 1 ton
• Factor of safety: 4:1
• Conforms to BS EN 13157: 2004 + A1: 2009
• Blue painted finish

Sizing

• A: 350mm
• B: 95mm
• C: 90mm
• D: 22mm
• E: 110mm
• F: 21mm

Please note: Colours may appear slightly different in person than on your screen.
