ENER-J Dimmable + WiFi 1A Mini Receiver

Designed for flexible lighting control, the ENER-J Dimmable + Wi-Fi 1A Mini Receiver is a 100W RF + Wi-Fi dimmable magic receiver module for ECO SERIES wireless switches (switches not included). It works with the ENER-J Dimmable Wireless Kinetic Switch, or can be controlled on its own over Wi-Fi using the free ENERJSMART app, giving you convenient access to your lighting from anywhere.

This receiver can also convert traditional switches into 2-way switching, helping ensure the kinetic switch can still operate even if the hard-wired switch is off. For added convenience, it supports voice control via Alexa and Google Home. Suitable for a wide range of installations, it can pair with multiple switches to create 1–2 way, 3-way, or multi-way switch systems, and is compatible with halogen, incandescent, CFL, fluorescent and LED lamps.

Key features

• 100W RF + Wi-Fi dimmable receiver module
• Compatible with ECO SERIES wireless switches (switches not included)
• Works with the free ENERJSMART app for Wi-Fi control
• Voice control compatible with Alexa and Google Home
• Converts traditional switches into 2-way switching
• Pairs with up to 10 switches
• Compatible with halogen, incandescent, CFL, fluorescent and LED lamps

Specifications

• Max wattage: 100W
• Dimmable: Yes
• Colour: White
• Power consumption: <0. 1W
• Voltage range: AC100~250V 50/60Hz
• Temperature range: -20C~50C
• Effective range: 80m (outdoor), 20m (indoor)
• Communication: RF 433MHz / RF 433MHz + 2. 4G Wi-Fi (app & voice control)
• Standards: EN61058-1; 2002+A2; 2008; GB 14536. 1-2008
• Software support end date: 10/08/2028

Sizing

L64*W32*H24mm

What's included

• 100W Dimmable Receiver RF+Wi-Fi
• User manual

Please note: Colours shown are as accurate as possible, though may vary slightly depending on your screen settings.

Rackhams Reference : BI8WC9AZ9D
