Fixaball M2 Socket Cap Allen Screw Bolt A4/316 Stainless Steel DIN 912

For corrosion-resistant metric fastening, this Fixaball M2 socket cap screw is made from A4/316 stainless steel and produced to DIN 912 and ISO 4762. It features a metric coarse M2 x 0.4mm pitch thread, a cylindrical head with hex socket drive, and suits applications where A4 stainless steel is specified.

The head diameter is 3.8mm, head height is 2mm, and it takes a 1.5mm Allen key. Lengths available run from M2 x 3 to M2 x 20, with bolt length measured excluding the head.

Available options

• M2 x 3
• M2 x 4
• M2 x 5
• M2 x 6
• M2 x 8
• M2 x 10
• M2 x 12
• M2 x 14
• M2 x 16
• M2 x 18
• M2 x 20

Key features

• Material: A4/316 stainless steel
• Finish: none
• Thread: metric coarse M2 x 0.4mm pitch
• Standards: DIN 912, ISO 4762
• Level of corrosion resistance: marine grade
• Typical application: constant weathering

Sizing

• Head diameter: 3.8mm
• Head height: 2mm
• Allen key size: 1.5mm
• Available lengths: M2 x 3, M2 x 4, M2 x 5, M2 x 6, M2 x 8, M2 x 10, M2 x 12, M2 x 14, M2 x 16, M2 x 18, M2 x 20

Please note: Bolt lengths do not include the head.

Rackhams Reference : CAVANCJ8R4
