Fixaball Socket Shoulder Cap Screw M20 Thread 24mm Shoulder DIN9841

For precision fastening in mechanical assemblies, this Fixaball socket shoulder cap screw combines an M20 metric coarse thread with a 24mm shoulder. Made from blackened alloy steel in grade 12.9, it is suited to applications where a cylindrical unthreaded shoulder is required before the threaded section. The internal hex drive allows installation with an Allen key.

The shoulder section supports rotational movement between parts, making this format suitable for moving components and other mechanical uses. Standards include DIN 9841, BS 4168 and ISO 7379.

Key features

• M20 metric coarse thread
• 24mm shoulder
• Blackened alloy steel
• Grade 12.9
• Internal hex drive
• Standards: DIN 9841, BS 4168, ISO 7379

Specifications

• Hardness: 38 HRC
• Tensile strength: 1200 N/mm²
• Temperature range: -50C to +300C
• Thread length (max): 27.4
• Diameter of shoulder: 23.98
• Socket head diameter: 36
• Hex/Allen key size: 12

Available options

• Shoulder length: 40mm
• Shoulder length: 50mm
• Shoulder length: 55mm
• Shoulder length: 60mm
• Shoulder length: 65mm
• Shoulder length: 70mm
• Shoulder length: 80mm
• Shoulder length: 90mm
• Shoulder length: 100mm
• Shoulder length: 110mm
• Shoulder length: 120mm

Rackhams Reference : C4THLTJYXJ
