Monstershop Aluminium Radiator & Valves - 1800mm x 315mm - Anthracite Grey

Bring a crisp, contemporary look to your heating with the Monstershop aluminium radiator and thermostatic valve set. Finished in anthracite grey, this flat panel design measures 1800mm x 315mm and uses 2.5mm aluminium with a triple layered powder coating for a durable, hard-wearing surface.

With 4 columns and individual panel sizing of 1800mm x 75mm, it delivers a BTU rating of 5856 at 60 (4575 at 50). Standard 0.5" BSP inlets/outlets support compatibility with all UK & EU heating systems, while the included angled thermostatic valves in polished chrome provide rotary knob control with a 6–28 degrees temperature range. A lockshield function is included to regulate water flow, and a flexible cleaning brush is supplied for straightforward upkeep. CE and UKCA certification, plus testing to BS EN 442 and ISO9001:2015 standards, complete the specification.

Key features

• Monstershop flat panel aluminium radiator with thermostatic valve set
• Size: 1800mm x 315mm; 4 columns
• Material: 2.5mm aluminium; triple layered powder coating
• BTU rating: 5856 at 60; 4575 at 50
• Standard 0.5" BSP bore inlets/outlets; compatible with all UK & EU heating systems
• Angled thermostatic valves with rotary knob control and lockshield function
• CE and UKCA certified; tested to BS EN 442 and ISO9001:2015 standards
• 15-year guarantee (radiator) and 10-year guarantee (valves)

Specifications

Radiator

• Colour: Anthracite grey
• Weight: 10.3kg
• Material: 2.5mm aluminium
• Finish: Triple layered powder coating
• Height: 1800mm / 180cm / 70.9”
• Width: 315mm / 31.5cm / 12.4”
• Radiator depth: 77mm / 7.7cm / 3”
• Depth with bracket: 105mm / 10.5cm / 4.1”
• Gap between panels: 50mm / 5cm / 2”
• Individual panel size: 1800mm x 75mm
• Number of columns: 4
• BTU rating @ 50: 4575
• BTU rating @ 60: 5856
• Inlets/outlets size: Standard 0.5" BSP bore
• Compatibility: All UK & EU heating systems
• Testing: BS EN 442 & ISO9001:2015 standards
• CE certificate: CE & UKCA

Valves

• Material: Brass
• Finish: Polished chrome
• Weight: 0.9kg
• Style: Angled
• Control style: Rotary knob
• Type: Thermostatic
• Temperature range: 6-28 degrees
• Maximum bar pressure: 12
• Maximum flow temperature: 100 degrees
• Nominal flow rate: 2.8L/m
• Connection: 1/2" x 15mm
• Guarantee length: 10 years

In the box

• 1 x Aluminium radiator
• 4 x Secure brackets
• 1 x Practical fixing kit
• 1 x Flexible cleaning brush
• 1 x Thermostatic valve set

Please note: Colours shown are as accurate as possible, though may vary slightly depending on your screen settings.
