Fixaball M2 Socket Cap Allen Screw Bolt A2/304 Stainless Steel DIN 912

For small-format fastening applications, this Fixaball M2 socket cap screw is manufactured from A2/304 stainless steel with a plain finish. Produced to DIN 912 and ISO 4762, it features a hexagon socket drive and a cylindrical cap head.

The thread is metric coarse M2 x 0.4mm pitch. Head diameter is 3.8mm, head height is 2mm, and it takes a 1.5mm Allen key. Bolt lengths do not include the head. Suitable for external use with intermittent weathering.

Available options

• M2 x 3
• M2 x 4
• M2 x 5
• M2 x 8
• M2 x 10
• M2 x 12
• M2 x 14
• M2 x 16
• M2 x 18
• M2 x 20
• M2 x 22
• M2 x 25
• M2 x 30

Key features

• Material: A2/304 stainless steel
• Finish: none
• Thread: metric coarse M2 x 0.4mm pitch
• Standard: DIN 912
• ISO 4762 cap screw

Specifications

• Head diameter: 3.8mm
• Head height: 2mm
• Allen key size: 1.5mm
• Bolt lengths do not include the head
• Suitable for external use with intermittent weathering

Rackhams Reference : ZS25S3AFZE
