Fixaball M6 Socket Cap Allen Screw Bolt 12.9 Self Colour

For engineering and mechanical fastening, this Fixaball M6 socket cap screw bolt combines a standard coarse M6 x 1.0mm pitch thread with a high tensile steel Grade 12.9 construction. Finished in self-colour black, it is produced to DIN 912 and ISO 4762.

The cylindrical cap head has a 10.2mm diameter and a 6mm head height, with a 5mm Allen key size. Length options are available across fully threaded and partially threaded versions, and stated bolt lengths do not include the head.

Available options

• 6mm length, fully threaded
• 8mm length, fully threaded
• 10mm length, fully threaded
• 12mm length, fully threaded
• 14mm length, fully threaded
• 15mm length, fully threaded
• 16mm length, fully threaded
• 18mm length, fully threaded
• 20mm length, fully threaded
• 22mm length, fully threaded
• 25mm length, fully threaded
• 30mm length, fully threaded
• 35mm length, partially threaded
• 40mm length, partially threaded
• 45mm length, partially threaded
• 50mm length, partially threaded
• 55mm length, partially threaded
• 60mm length, partially threaded
• 65mm length, partially threaded
• 70mm length, partially threaded
• 75mm length, partially threaded
• 80mm length, partially threaded
• 85mm length, partially threaded
• 90mm length, partially threaded
• 100mm length, partially threaded
• 110mm length, partially threaded
• 120mm length, partially threaded
• 130mm length, partially threaded
• 135mm length, partially threaded
• 140mm length, partially threaded

Key features

• High tensile steel Grade 12.9
• Self-colour black finish
• Metric coarse M6 x 1.0mm pitch thread
• DIN 912 and ISO 4762
• 5mm Allen key size

Sizing

• Head diameter: 10.2mm
• Head height: 6mm
• Available lengths: 6mm, 8mm, 10mm, 12mm, 14mm, 15mm, 16mm, 18mm, 20mm, 22mm, 25mm, 30mm, 35mm, 40mm, 45mm, 50mm, 55mm, 60mm, 65mm, 70mm, 75mm, 80mm, 85mm, 90mm, 100mm, 110mm, 120mm, 130mm, 135mm, 140mm

Specifications

• Fully threaded lengths: 6mm, 8mm, 10mm, 12mm, 14mm, 15mm, 16mm, 18mm, 20mm, 22mm, 25mm, 30mm
• Partially threaded lengths: 35mm, 40mm, 45mm, 50mm, 55mm, 60mm, 65mm, 70mm, 75mm, 80mm, 85mm, 90mm, 100mm, 110mm, 120mm, 130mm, 135mm, 140mm
• Bolt lengths do not include the head

Rackhams Reference : BJP82ZXFPM
