Monstershop Flat Single Column Radiator & Valves – 600mm x 1400mm – Black

Bring a crisp, architectural look to your heating with the Monstershop Flat Single Column Radiator & Valves set. Finished in black with a triple layered powder coating, this 600mm x 1400mm radiator pairs clean lines with a substantial 20-column format, making it a strong choice for contemporary interiors where the radiator is part of the room’s design.

Made from 1.5mm carbon steel, it uses 60mm x 15mm flat tubes with a 10mm gap between tubes. Heat output is rated at 3433 BTU at 50 and 4335 BTU at 60 (1006W at 50 and 1270W at 60), with a recommended application area of 13m². Standard 0.5" BSP inlets/outlets support straightforward integration with UK and EU heating systems, while the supplied angled thermostatic valve set in polished chrome provides rotary control with a 6–28 degrees temperature range. CE and UKCA certification is included, alongside testing to BS EN 442 and ISO9001:2015 standards.

Key features

• Flat single column radiator with 20 columns
• Black finish with triple layered powder coating
• Heat output: 4335 BTU at 60 (1270W at 60)
• Standard 0.5" BSP bore inlets/outlets
• Supplied with angled thermostatic valve set (polished chrome)
• Includes secure brackets, fixing kit and flexible cleaning brush
• 15-year guarantee on the radiator
• 10-year guarantee on the valve set

Specifications

Radiator

• Material: 1.5mm carbon steel
• Colour: Black
• Weight: 22.8kg
• Height: 600mm / 60cm / 23.6”
• Width: 1400mm / 140cm / 55.1”
• Radiator depth: 46mm / 4.6cm / 1.8”
• Depth with bracket: 73mm / 7.3cm / 2.9”
• Individual flat tube size: 60mm x 15mm
• Gap between tubes: 10mm / 1cm / 0.4”
• BTU rating @ 50: 3433
• BTU rating @ 60: 4335
• Watt rating @ 50: 1006
• Watt rating @ 60: 1270
• Max working temperature: 95°C
• Max working pressure: 5 Bar
• Test pressure: 6.5 Bar
• Recommended application area: 13m²
• Inlets/outlets size: Standard 0.5" BSP bore
• Distance from wall to centre of inlet: 44mm / 4.4cm / 1.7”
• Valve-to-valve height: 549mm / 54.9cm / 21.6”
• Compatibility: All UK & EU heating systems
• Testing: BS EN 442 & ISO9001:2015 standards
• Certification: CE & UKCA

Valves

• Type: Thermostatic
• Style: Angled
• Control style: Rotary knob
• Material: Brass
• Finish: Polished chrome
• Weight: 0.9kg
• Temperature range: 6-28 Degrees
• Maximum bar pressure: 12
• Maximum flow temperature: 100 Degrees
• Nominal flow rate: 2.8L/m
• Connection: 1/2" x 15mm

In the box

• 1 x Flat single column radiator
• 4 x Secure brackets
• 1 x Practical fixing kit
• 1 x Flexible cleaning brush
• 1 x Thermostatic valve set

Please note: Colours shown are as accurate as possible, though may vary slightly depending on your screen settings.
