Fixaball M6 Throughbolts A2 Stainless Steel Heavy Duty Masonry Concrete Anchor

For masonry and concrete fixings, the Fixaball M6 throughbolt provides a stainless steel expansion anchor in A2/304 grade. It is suitable for fixing materials to non-cracked concrete, masonry including brick and blocks, and non-porous stone.

This torque-controlled anchor is intended for through fixing, with the hole diameter matching the bolt diameter. It allows the fixing to pass through the fixture once positioned, which is useful when securing awkward fixtures in place. The anchor is suitable for use in concrete over C20/25 strength.

Key features

• Diameter: M6
• Material: A2/304 stainless steel
• Expansion anchor for non-cracked concrete, masonry and non-porous stone
• Torque-controlled anchor
• Suitable for use in concrete over C20/25 strength

Specifications

• Installation temperature range for base material: -5 / + 40 ºC
• Short-term temperature: 80 ºC
• Hole diameter matches bolt diameter

Available options

• 6mm x 40mm
• 6mm x 65mm

Sizing

• Anchor diameter: 6
• Anchor length: 50mm
• Max. thickness: 10mm
• Hole diameter: -
• Anchor length: 65mm
• Max. thickness: 25mm
• Hole diameter: 5
• Anchor length: 85mm
• Max. thickness: 45mm
• Hole diameter: 25
• Anchor length: 100mm
• Max. thickness: 60mm
• Hole diameter: 40

Safety information

• Check the concrete strength, grade and edge distance before installation.
• Use only in compact, crack-free concrete.
• Minimum installation depth, anchor-to-anchor distances and anchor-to-edge distances must be respected.
• Drill to the specified minimum depth and diameter, perpendicular to the base material surface.
• Take care when drilling near reinforcement areas to avoid damage.
• Clean holes thoroughly to remove dust and debris with a suitably sized brush.
• When temperature is below 0ºC, prevent water from seeping into the hole.
• Do not apply any intermediate layer between the material being fixed and the washer.
• Apply the specified torque with a torque wrench.

Rackhams Reference : XTGUSHCMNW
