Monstershop Traditional 4 Column Radiator & Valves - 600 x 1010mm - White

A classic column look meets modern specification in the Monstershop Traditional 4 Column Radiator & Valves. Finished in white with a triple layered powder coating, it brings a clean, architectural presence to living spaces, hallways and larger rooms where a horizontal format suits the wall.

Made from 1.5mm carbon steel, this 600mm high radiator measures 1010mm wide and uses 25mm steel tubes with 20mm gaps between them. Heat output is rated at 3437 BTU at 50 and 4367 BTU at 60 (1007 watts at 50 and 1280 watts at 60). Supplied with a chrome thermostatic valve set in an angled style, temperature can be adjusted from 6–28 degrees via a rotary knob, with an integrated lockshield valve for regulating water flow. CE and UKCA certification is included, alongside testing to BS EN 442 and ISO9001:2015 standards.

Key features

• Traditional 4 column horizontal radiator
• White finish with triple layered powder coating
• Made from 1.5mm carbon steel
• Heat output: 4367 BTU at 60 (1280 watts at 60)
• Standard 0.5" BSP bore inlets/outlets
• Supplied with angled chrome thermostatic valve set
• Temperature range: 6–28 degrees (rotary knob control)
• Includes brackets, fixing kit and flexible cleaning brush
• 15-year guarantee (radiator) and 10-year guarantee (valves)

Specifications

Radiator

• Colour: White
• Material: 1.5mm carbon steel
• Weight: 51kg
• Finish: Triple layered powder coating
• Height: 600mm / 60cm / 23.6”
• Width: 1010mm / 101cm / 39.8”
• Radiator depth: 140mm / 14cm / 5.5”
• Depth with bracket: 155mm / 15.5cm / 6.1”
• Gap between tubes: 20mm / 2cm / 0.8”
• Individual tube size: 25mm / 2.5cm / 1”
• Number of columns: 22
• BTU rating @ 50: 3437
• BTU rating @ 60: 4367
• Watt rating @ 50: 1007
• Watt rating @ 60: 1280
• Max working temperature: 95°C
• Max working pressure: 12 bar
• Test pressure: 15.6 bar
• Recommended application area: 13m²
• Inlets/outlets size: Standard 0.5" BSP bore
• Distance from wall to centre of inlet: 85mm
• Valve-to-valve height: 520mm / 52cm / 20.5”
• Compatibility: All UK & EU heating systems
• Testing: BS EN 442 & ISO9001:2015 standards
• CE certificate: CE & UKCA

Valve set

• Colour: Silver chrome
• Material: Powder coated brass
• Weight: 0.9kg
• TRV dimensions: 137mm H x 85mm W x 55mm D
• Lockshield dimensions: 87mm H x 75mm W x 34mm D
• Style: Angled
• Control style: Rotary knob
• Type: Thermostatic
• Temperature range: 6-28 degrees
• Maximum bar pressure: 10
• Maximum flow temperature: 100 degrees
• Nominal flow rate: 2.8L/m
• Connection: 1/2" x 15mm
• Guarantee length: 10 years

In the box

• 1 x Traditional 4 column radiator
• 4 x Secure brackets
• 1 x Practical fixing kit
• 1 x Flexible cleaning brush
• 1 x Thermostatic valve set
