Monstershop Traditional 4 Column Radiator & Valves - 600 x 785mm - Anthracite Grey

A bold, architectural update for modern and traditional interiors alike, the Monstershop Traditional 4 Column Radiator & Valves combines a horizontal, multi-column profile with a deep anthracite grey finish. Made from 1.5mm carbon steel and finished with triple layered powder coating, it brings a clean, structured look to living spaces, hallways and home offices where a statement radiator suits the room.

Measuring 600mm high by 785mm wide, this 17-column radiator uses 25mm steel tubes with 20mm gaps between tubes. Heat output is rated at 2655 BTU at 50 and 3373 BTU at 60, with watt ratings of 595 at 50 and 756 at 60. Supplied with secure brackets, a fixing kit and a flexible cleaning brush, it also includes a chrome thermostatic valve set with angled valves and rotary control, offering a 6–28 degrees temperature range. CE and UKCA certification, BS EN 442 testing and a 15-year guarantee complete the specification.

Key features

• Traditional style 4 column horizontal radiator with thermostatic valve set
• 600mm x 785mm size
• Anthracite grey finish with triple layered powder coating
• 1.5mm carbon steel construction
• Heat output: 3373 BTU at 60 (2655 BTU at 50)
• Standard 0.5" BSP inlet/outlet size
• Supplied with brackets, fixing kit and flexible cleaning brush
• CE and UKCA certified; tested to BS EN 442 and ISO9001:2015 standards
• 15-year guarantee (radiator) and 10-year guarantee (valves)

Specifications

Radiator

• Colour: Anthracite Grey
• Material: 1.5mm Carbon Steel
• Finish: Triple Layered Powder Coating
• Weight: 38.6kg
• Height: 600mm / 60cm / 23.6”
• Width: 785mm / 78.5cm / 30.9”
• Radiator Depth: 140mm / 14cm / 5.5”
• Depth With Bracket: 155mm / 15.5cm / 6.1”
• Gap Between Tubes: 20mm / 2cm / 0.8”
• Individual Tube Size: 25mm / 2.5cm / 1”
• Number Of Columns: 17
• BTU Rating @ 50: 2655
• BTU Rating @ 60: 3373
• Watt Rating @ 50: 595
• Watt Rating @ 60: 756
• Max Working Temperature: 95°C
• Max Working Pressure: 12 Bar
• Test Pressure: 15.6 Bar
• Recommended Application Area: 10m²
• Inlets/Outlets Size: Standard 0.5" BSP Bore
• Distance From Wall To Centre Of Inlet: 85mm
• Valve-To-Valve Height: 520mm / 52cm / 20.5”
• Compatibility: All UK & EU Heating Systems
• Testing: BS EN 442 & ISO9001:2015 Standards
• CE Certificate: CE & UKCA

Valves

• Colour: Silver Chrome
• Material: Powder Coated Brass
• Weight: 0.9kg
• TRV Dimensions: 137mm H x 85mm W x 55mm D
• Lockshield Dimensions: 87mm H x 75mm W x 34mm D
• Style: Angled
• Control Style: Rotary Knob
• Type: Thermostatic
• Temperature Range: 6-28 Degrees
• Maximum Bar Pressure: 10
• Maximum Flow Temperature: 100 Degrees
• Nominal Flow Rate: 2.8L/m
• Connection: 1/2" x 15mm
• Guarantee Length: 10 Years

In the box

• 1 x Traditional 4 Column Radiator
• 4 x Secure Brackets
• 1 x Practical Fixing Kit
• 1 x Flexible Cleaning Brush
• 1 x Thermostatic Valve Set

Please note: Colours shown are as accurate as possible, though may vary slightly depending on your screen settings.
