Monstershop Traditional 4 Column Radiator & Valves - 1800 x 380mm - Anthracite Grey

Bring a confident, architectural look to your heating with the Monstershop Traditional 4 Column Radiator & Valves. Finished in anthracite grey with a triple layered powder coating, it pairs a classic column profile with a tall 1800mm vertical format that suits a wide range of rooms.

Made from 1.5mm carbon steel, this radiator measures 380mm wide and 140mm deep (155mm with bracket). Heat output is rated at 6171 BTU at 50 and 7863 BTU at 60, with a maximum working temperature of 95°C and maximum working pressure of 12 bar. Standard 0.5" BSP inlets/outlets support straightforward integration with UK and EU heating systems, while the supplied angled chrome thermostatic valve set offers rotary control with a 6–28 degrees temperature range and an integrated lockshield valve.

Key features

• Traditional column radiator with anthracite grey finish
• Triple layered powder coating
• Heat output: 7863 BTU at 60
• Standard 0.5" BSP bore inlets/outlets
• Supplied with angled thermostatic valve set (rotary knob control)
• Includes secure brackets and fixing kit
• Flexible cleaning brush included
• 15 year guarantee

Specifications

Radiator

• Colour: Anthracite Grey
• Material: 1.5mm Carbon Steel
• Finish: Triple Layered Powder Coating
• Weight: 54.5kg
• Height: 1800mm / 180cm / 70.9”
• Width: 380mm / 38cm / 15”
• Radiator Depth: 140mm / 14cm / 5.5”
• Depth With Bracket: 155mm / 15.5cm / 6.1”
• Gap Between Tubes: 20mm / 2cm / 0.8”
• Individual Tube Size: 25mm / 2.5cm / 1”
• Number Of Columns: 8
• BTU Rating @ 50: 6171
• BTU Rating @ 60: 7863
• Watt Rating @ 50: 1808
• Watt Rating @ 60: 2304
• Max Working Temperature: 95°C
• Max Working Pressure: 12 Bar
• Test Pressure: 15.6 Bar
• Recommended Application Area: 23m²
• Inlets/Outlets Size: Standard 0.5" BSP Bore
• Distance From Wall To Centre Of Inlet: 85mm
• Valve-To-Valve Height: 1720mm / 172cm / 67.7”
• Compatibility: All UK & EU Heating Systems
• Testing: BS EN 442 & ISO9001:2015 Standards
• CE Certificate: CE & UKCA

Valve set

• Colour: Silver Chrome
• Material: Powder Coated Brass
• Weight: 0.9kg
• TRV Dimensions: 137mm H x 85mm W x 55mm D
• Lockshield Dimensions: 87mm H x 75mm W x 34mm D
• Style: Angled
• Control Style: Rotary Knob
• Type: Thermostatic
• Temperature Range: 6-28 Degrees
• Maximum Bar Pressure: 10
• Maximum Flow Temperature: 100 Degrees
• Nominal Flow Rate: 2.8L/m
• Connection: 1/2" x 15mm
• Guarantee Length: 10 Years

In the box

• 1 x Traditional 4 Column Radiator
• 4 x Secure Brackets
• 1 x Practical Fixing Kit
• 1 x Flexible Cleaning Brush
• 1 x Thermostatic Valve Set

Please note: Colours shown are as accurate as possible, though may vary slightly depending on your screen settings.
