Monstershop Traditional 4 Column Radiator & Valves - 1800 x 380mm - Black

A bold, architectural update for modern and traditional interiors alike, the Monstershop Traditional 4 Column Radiator & Valves combines a tall vertical profile with a deep black finish. This carbon steel radiator measures 1800mm high by 380mm wide, with a 140mm depth, making it a strong option for spaces where wall height is available.

Built from premium 1.5mm carbon steel and finished with triple layered powder coating, it pairs durability with a clean, defined look. Heat output is rated at 6171 BTU at 50 and 7863 BTU at 60 (1808W at 50 and 2304W at 60), with a recommended application area of 23m². Standard 0.5" BSP inlets/outlets support straightforward integration, while the supplied satin brass thermostatic valve set offers rotary control with a 6–28 degrees temperature range and an integrated lockshield valve.

Key features

• Traditional-style vertical radiator with black finish
• Premium 1.5mm carbon steel construction
• Triple layered powder coating
• Heat output: 6171 BTU at 50 and 7863 BTU at 60
• Supplied with angled thermostatic valve set (rotary knob control)
• Standard 0.5" BSP bore inlets/outlets
• CE and UKCA certified; tested to BS EN 442 and ISO9001:2015 standards
• 15-year guarantee (radiator) and 10-year guarantee (valves)

Specifications

Radiator

• Colour: Black
• Material: 1.5mm carbon steel
• Finish: Triple layered powder coating
• Weight: 54.5kg
• Height: 1800mm / 180cm / 70.9”
• Width: 380mm / 38cm / 15”
• Radiator depth: 140mm / 14cm / 5.5”
• Depth with bracket: 155mm / 15.5cm / 6.1”
• Gap between tubes: 20mm / 2cm / 0.8”
• Individual tube size: 25mm / 2.5cm / 1”
• Number of columns: 8
• BTU rating @ 50: 6171
• BTU rating @ 60: 7863
• Watt rating @ 50: 1808
• Watt rating @ 60: 2304
• Max working temperature: 95°C
• Max working pressure: 12 bar
• Test pressure: 15.6 bar
• Recommended application area: 23m²
• Inlets/outlets size: Standard 0.5" BSP bore
• Distance from wall to centre of inlet: 85mm
• Valve-to-valve height: 1720mm / 172cm / 67.7”
• Compatibility: All UK & EU heating systems
• Testing: BS EN 442 & ISO9001:2015 standards
• CE certificate: CE & UKCA

Valve set

• Colour: Brass
• Material: Powder coated brass
• Weight: 0.9kg
• TRV dimensions: 137mm H x 85mm W x 55mm D
• Lockshield dimensions: 87mm H x 75mm W x 34mm D
• Style: Angled
• Control style: Rotary knob
• Type: Thermostatic
• Temperature range: 6-28 degrees
• Maximum bar pressure: 10
• Maximum flow temperature: 100 degrees
• Nominal flow rate: 2.8L/m
• Connection: 1/2" x 15mm
• Guarantee length: 10 years

In the box

• 1 x Traditional 4 column radiator
• 4 x Secure brackets
• 1 x Practical fixing kit
• 1 x Flexible cleaning brush
• 1 x Thermostatic valve set

Please note: Colours shown are as accurate as possible, though may vary slightly depending on your screen settings.
